Description
Feature
- Equipped with imported high-rigidity horizontal hydraulic servo turret,high positioning accuracy, fast tool changing speed in the vicinity, and small deformation during heavy cutting.
- The inclined bed structure is 45°, and cast with high-quality resin sand, which has good rigidity, good shock resistance and smooth chip removal.
- High-precision hydraulic chuck, high-precision clamping, convenient and fast.
- The electrical cabinet of the machine has good sealing performance and is equipped with air conditioners to ensure that the machine works normally in a high temperature and high humidity environment．
- The hydraulic pressure adjustment adopts the panel knob operation, and the dial display is convenient for adjustment.
Technical Parameters
Configuration
Unit
HCNT X-3200
Machining Capacity
Maximum Swing Over Bed
ø /mm
320
Maximum Swing Over Slide
ø /mm
140
Maximum Machining Length
mm
240
Maximum Diameter of Bar
ø /mm
40
Permanent Magnet Synchronous Motorized Spindle
Spindle Head Type
GB59001
A2-5
Spindle Taper Hole
ø /mm
52
Spindle Speed Range
r/min
60-5000
Spindle Shift Mode
Servo
Spindle Output Torque
N·m
110
Chuck Type
Hydraulic Through Chuck
Chuck Size
Inch
6"
Feed Rate
Rapid Traverse Speed On X-axis
m/min
25
Rapid Traverse Speed On Z-axis
m/min
25
Servo Motor Torque On X-axis
N·m
6
Servo Motor Torque On Z-axis
N·m
6
X-axis Travel
mm
160
Z-axis Travel
mm
300
Guideway Type
Roller Linear Guideway
Turret
Turret Type
Hydraulic Servo 8 Post Turret
Turning Tools / Boring Bar Size
mm
20×20/φ25
Tailstock
Tailstock Type
Hydraulic
Tailstock Sleeve Diameter
ø /mm
65
Tailstock Sleeve Travel
mm
70
Internal Taper of Tailstock Sleeve
MT4
Power source
Total Rated Power
KVA
10
Total Rated Current
A
20
Dimension
Machine Weight
kg
2200
Machine Dimension L×W×H(mm)
Mm
2120×1675×1900
Optional
Chip Conveyor
Hinge-Belt
Optional Servo Spindle
Spindle Speed Range
r/min
60-4000
Main Motor Power
KW
3.7
Spindle Taper Hole
ø /mm
52
Spindle Head Type
GB59001
A2-5
